HF_MAP Sky Wave propagation Screenshots
How to install HF_MAP Sky Wave propagation apk for android
- For Android 4.0 or higher:Please to Settings, look down to Security, and select Unknown sources. Choosing this choice will enable to install apps download from the internet.
- For devices running on lower Android 4.0:
Please go to Settings - open the Applications option, and select Unknown sources, click OK on the popup alert.
HF_MAP Sky Wave propagation Description
HF_MAP a graphical view to sky-wave propagation (short-wave 1-30MHz):Each map is build for a constant location and display the frequency to use to reach any other radio station worldwide.
There is a map for each hour of the day; the values are mean values of the selected month for the specified solar activity.
A 24-hour map set is more than 5000 point to point diagrams at once. The color scale steps are 2MHz.
You can view the variation during the day by touching the map, left side for -utc, right side for +utc. Depending on your
device the changes are very quick
Continent outline, sun position and the gray-line (transition between day and night) are displayed over the color map.
This let you observe how the frequency changes are related to the sun.
There are 5 different palettes for the used scale, for the 3-colour palette you can shift the band selection high and low.
See the screen shot of the touch areas on how to switch palettes.
Selection in the red background area of the main screen:
Solar activity, month, map type and the draw the map button.
Constant location about Europe centre, 3-country corner of France, Germany and Switzerland (47.6 North / 7.6 East).
The maps are usable as long the location is not much more than 200Km from this point.
Each month is computed for 6 different solar activities
Sun Spot Number 10, 30, 60, 90, 120, 150 / 10cm solar flux: 71, 86, 111, 136, 164, 193
The map values are:
MUF Maximum Usable Frequency (50% probability)
FOT Frequency of Optimum Traffic (90% probability)
HPF Highest Possible Frequency (10% probability) (sun spot number 10 and 30 only!)
1 MHz atmospheric noise (dB)
Total about 180 map sets to 24 hours.
Selection in the green area of the main screen:
Sets of maps for other constant locations as used during DX expeditions (94 sets).
There are maps for FOT, MUF, HPF and number of hops for the locations:
Florida, Malmo, Vienna, New Delhi, Singapore, Con Co Island, Peter One Island, Corvo Island, Agalega Island, St.Brandon Island,
Heard Island and the Palmyra DX Expedition.
This App was tested using a Samsung Galaxy S2.
For user far from central Europe, take MyHFMap to create coverage maps from your own sender position!
follow us on Facebook
http://www.facebook.com/pages/HF_Map/479760022055348
What's new in HF_MAP Sky Wave propagation 4.0
Version 3.0 (December 4. 2012):1. new layout, map at full screen for each device
2. continent map overlay at a better resolution
Version 4.0 (December 29. 2012):
- Fix for color legend at high resolution client
